This page serves as a guide for implementing an S2 RM for a heat pump, or to give a CEM developer a better understanding of what to expect when controlling the energy flexibility of a heat pump. It provides some example S2 messages for same (fictional) heat pumps.
How is a heat pump flexible?
A heat pump is a device that uses electricity to heat a building and/or Domestic Hot Water (DHW). A heat pump can do this efficiently by utilizing a heat source (typically the air or ground). In this guide we'll make the distinction between an all electric heat pump (which provides the heat for a building on its own) and a hybrid heat pump (which is typically a smaller heat pump which uses a natural gas boiler for peak demands). When a heat pump provides DHW, it typically uses a buffer tank to store an amount of hot water.
There are in principle three ways a heat pump can be energy flexible. Depending on the set-up, these forms of energy flexibility can be combined.
- Using the Domestic Hot Water (DHW) buffer as a source of energy flexibility
Allow some variation in the water temperature, or don't heat the buffer immediately after DHW consumption. This requires a bit larger DHW buffer than strictly necessary, or a reliable forecast of when what amount of DHW is required.
- Using the thermal mass of the building as a source for energy flexibility
Reduce or stop heating the building for a certain period, without significantly affecting the room temperature. Preheating (again, without significantly affecting the room temperature) could even prolong the period in which the heat pump can turn off or reduce its power. This is typically implemented by defining a small temperature bandwidth (e.g. half a degree Celsius) around the thermostat set point.
- (Hybrid heat pump only) Switching between electricity and natural gas
A hybrid heat pump can temporarily reduce or stop its electricity consumption by starting or increasing the power of the natural gas boiler. This way, the heat output of the hybrid heat pump isn't significantly affected.
Choosing the right Control Type
When implementing S2, it's important to choose the right Control Type(s) to implement in the RM of the heat pump. S2 is a language for conveying energy flexibility to the CEM without making any assumptions on what the CEM is optimizing for. Although there typically are multiple Control Types that can be used for a heat pump, it is preferred to pick the one that conveys the most information and control options to the CEM, so the CEM can do the best optimization that adds the most value.
As a general rule, when there is some form of energy (in this case heat) buffering involved, Fill Rate Base Control (FRBC) is the best Control Type. When there is no flexibility involved, but there is an option to switch between different fuels (as is the case with the hybrid heat pump), Demand Driven Based Control (DDBC) typically is the best option. Both Control Types give the CEM relatively direct control over the heat pump.
However, in S2 it is up to the RM to implement whatever Control Type it seems best, or it can even implement multiple Control Types. There are two alternatives that still allow the CEM to utilize the energy flexibility of the heat pump, but give less direct control over the heat pump. The risk of these control types is that CEM might utilize the energy flexibility less effective or that it makes the energy flexibility of the heat pump not usable for certain use cases, decreasing the value of the energy flexibility.
The first alternative Control Type is Power Envelope Based Control (PEBC). With PEBC, the CEM cannot control the heat pump, but it can request it to limit its energy consumption for certain moments. The Resource Manager defines how the CEM is allowed to limit the consumption. It is preferred (but not mandatory) that the RM provides a forecast of the energy consumption.
The second alternative Control Type is Power Profile Based Control (PPBC). Here the RM could offer the CEM some alternative power profiles for the near future to choose from. It could, for example, offer a power profile where it starts heating DHW right away, and an alternative one where it does it later. It is for this Control Type necessary that the RM can make forecasts for the near future.
The possible Control Types to implement are summarized in the table below.
| DHW buffer | Thermal mass building | Switching between natural gas and electricity (hybrid heat pump only) | Preferred Control Type | Alternative Control Type |
|---|---|---|---|---|
| No | No | No | n/a | n/a |
| Yes | No | No | FRBC | PEBC or PPBC |
| No | Yes | No | FRBC | PEBC or PPBC |
| No | No | Yes | DDBC | PEBC or PPBC |
| Yes | Yes | No | FRBC | PEBC or PPBC |
| No | Yes | Yes | FRBC | PEBC or PPBC |
| Yes | No | Yes | FRBC | PEBC or PPBC |
| Yes | Yes | Yes | FRBC | PEBC or PPBC |
Example: All electric heat pump utilizing the DHW buffer using FRBC
In this example we will work out the communication between CEM and RM for an all electric heat pump that utilizes the DHW buffer for energy flexibility using FRBC.
The following sequence diagram is an example of what a message exchange between a CEM and RM could look like, but messages could also be sent in a different order (see also State of communication). ReceptionStatus messages are omitted for readability.
Details
Image generated using the following PlantUML code:
@startuml
note over CEM, RM: WebSocket connected
CEM -> RM: Handshake
RM -> CEM: Handshake
CEM -> RM: HandshakeResponse
note over CEM, RM: Initialized
RM -> CEM: ResourceManagerDetails
CEM -> RM: SelectControlType
note over CEM, RM: ControlType activated
RM -> CEM: FRBC.SystemDescription
RM -> CEM: FRBC.LeakageBehaviour
loop in no particular order
RM -> CEM: PowerMeasurement
RM -> CEM: FRBC.ActuatorStatus
RM -> CEM: FRBC.StorageStatus
RM -> CEM: FRBC.TimerStatus
RM -> CEM: FRBC.UsageForecast
CEM -> RM: FRBC.Instruction
RM -> CEM: InstructionStatusUpdate
end loop
RM -> CEM: SessionRequest
note over CEM, RM: WebSocket disconnected
@enduml
CEM -> RM: Handshake
The CEM informs the RM that it is a CEM and which versions of s2-ws-json it supports.
{
"message_type": "Handshake",
"message_id": "4834583e-5d8a-4fb2-a955-c99fc4583b7a",
"role": "CEM",
"supported_protocol_versions": [
"0.0.2-beta"
]
}
RM -> CEM: Handshake
The RM informs the CEM that it is a RM and which versions of s2-ws-json it supports.
{
"message_type": "Handshake",
"message_id": "164deb3f-952f-42d4-bebb-4666e8baa62e",
"role": "RM",
"supported_protocol_versions": [
"0.0.2-beta"
]
}
CEM -> RM: HandshakeResponse
The CEM informs the RM which version of s2-ws-json it has selected for this session.
{
"message_type": "HandshakeResponse",
"message_id": "7fd890a4-766e-4c66-9859-470daec3cdf9",
"selected_protocol_version": "0.0.2-beta"
}
RM -> CEM: ResourceManagerDetails
The RM informs the CEM about several static properties of the RM/heat pump:
- The resource_id is a unique string in the context of the CEM.
- The name is a default name or user defined name (when possible) for UI purposes.
- In this context the heat pump is an electricity consumer, and not a heat producer or storage. S2 is concerned with what is exchanged with the grid, and in this case the heat pump doesn't participate in a heat grid that needs to be managed by the CEM.
- The instruction processing delay indicates that the heat pump will on average respond in 10000 milliseconds to an instruction from the CEM.
- This heat pump does not define any costs related parameters, so no currency needs to be provided.
- This RM only implements the FRBC Control Type.
- This RM does not provide power forecasts.
- This heat pump is a single phase electric device (when there is only one phase the phase L1 must be used), so it will only provide measurements for the single phase.
{
"message_type": "ResourceManagerDetails",
"message_id": "a348da35-eb0c-456c-9099-cdcc22e030a0",
"resource_id": "acme_heat_pump",
"name": "my_heat_pump",
"roles": [
{
"role": "ENERGY_CONSUMER",
"commodity": "ELECTRICITY"
}
],
"manufacturer": "ACME",
"model": "HeatPump2000",
"serial_number": "123",
"firmware_version": "v1.0",
"instruction_processing_delay": 10000,
"available_control_types": [
"FILL_RATE_BASED_CONTROL"
],
"provides_forecast": false,
"provides_power_measurement_types": [
"ELECTRIC.POWER.L1"
]
}
CEM -> RM: SelectControlType
The CEM informs the RM that it wants to use FRBC ControlType (the RM defined in the ResourceManagerDetails that this is the only supported ControlType).
{
"message_type": "SelectControlType",
"message_id": "b44a8e22-ede6-4b1d-908f-72dd45c69106",
"control_type": "FILL_RATE_BASED_CONTROL"
}
RM -> CEM: FRBC.SystemDescription
The idea behind FRBC is that the RM describes an abstract device, which can be mapped to the physical device. The abstract device should be accurate enough for the CEM to create realistic plans and instructions. The FRBC.SystemDescription message defines this abstract device. This description usually pretty static, but can be updated by the RM if the parameters change (e.g. due to efficiency changes do to a changing outside temperature). The FRBC.SystemDecription is relatively large message, so we'll break it down in parts.
First of all we'll take a look at how the storage is described. The storage is an energy storage for which we know how full it is. The fullness of the buffer is described with a number called the fill level. How exactly energy is stored and what the exact unit of the fill level is is not that relevant to the CEM; it only cares about energy exchanged with the grid. In our case the storage is our DHW buffer, and we'll use the temperature in Celsius as the fill level. For comfort and efficiency reasons, we'll allow a water temperature anywhere between 45 and 55 degrees Celsius. If it is below 45, the DHW buffer MUST be heated for user comfort and the heat pump is no longer energy flexible. A temperature above 55 degrees Celsius is not desirable due to efficiency reasons. When the temperature is above 55 the heat pump cannot turn on and also isn't energy flexible. These two temperatures are defined as the fill level range.
For debugging purposes (so for humans, not for algorithms) a label is provided for the storage and the fill level. Also, it is indicated which information the storage provides. The fill level target is not relevant in our case, so it is not provided.
{
"diagnostic_label": "DHW Buffer",
"fill_level_label": "temperature in Celsius",
"provides_leakage_behaviour": true,
"provides_fill_level_target_profile": false,
"provides_usage_forecast": true,
"fill_level_range": {
"start_of_range": 45,
"end_of_range": 55
}
}
Secondly we'll define the heat pump itself. In FRBC this is referred to as an actuator. An actuator is something that the CEM can control, affects the fill level of the storage and exchanges power with the power grid (in our case, consuming electricity).
An actuator consists of operation modes, transitions (between operation modes) and timers (associated with transitions). An operation mode is defined for a fill_level_range. This allows for modeling non-linear behavior of the actuator. Furthermore, the operation mode contains a fill_rate which expresses how much the fill level changes in that operation mode, at a certain power consumption, which is defined in the power_range. This is used to model the relation between the actuator's consumed power and the effect on the fill level.
The actuator also defines the possible transitions between operation modes. Finally, it contains timers that can be used to model temporal prohibition of operation mode transitions.
Our heat pump has two operation modes. One for a heat pump that is idle and one for a running heat pump.
The operation mode 'running' is the most interesting. We have heat pump with a minimum operation power of 500 W and a maximum of 2000 W, and a fixed COP of 3.5 With a delta T of 10 degrees Celsius and a buffer that contain 200 L of water, the total energy to store is: 8380000 J. This means that the fill_rate at minimum power is: 10*500*3.5/8380000=0.00209 and at maximum power: 10*2000*3.5/8380000=0.00835. This means that the CEM has control over de modulation of the heat pump between its minimum and maximum power.
It is possible in S2 to associate cost to an operation mode or transition (for example to account for tear and wear associated with running or starting an appliance) but that does not apply to our simple heat pump model.
So, the actuator of our example heat pump looks as follows:
{
"id": "actuator1",
"diagnostic_label": "heat pump",
"supported_commodities": [
"ELECTRICITY"
],
"operation_modes": [
{
"id": "om0",
"diagnostic_label": "running",
"elements": [
{
"fill_level_range": {
"start_of_range": 45,
"end_of_range": 55
},
"fill_rate": {
"start_of_range": 0.00209,
"end_of_range": 0.00835
},
"power_ranges": [
{
"start_of_range": 500,
"end_of_range": 2000,
"commodity_quantity": "ELECTRIC.POWER.L1"
}
],
"running_costs": {
"start_of_range": 0,
"end_of_range": 0
}
}
],
"abnormal_condition_only": false
},
{
"id": "om1",
"diagnostic_label": "Off",
"elements": [
{
"fill_level_range": {
"start_of_range": 45,
"end_of_range": 55
},
"fill_rate": {
"start_of_range": 0,
"end_of_range": 0
},
"power_ranges": [
{
"start_of_range": 0,
"end_of_range": 0,
"commodity_quantity": "ELECTRIC.POWER.L1"
}
],
"running_costs": {
"start_of_range": 0,
"end_of_range": 0
}
}
],
"abnormal_condition_only": false
}
],
"transitions": [
{
"id": "trans0",
"from": "om0",
"to": "om1",
"start_timers": [
"timer0"
],
"blocking_timers": [
"timer1"
],
"transition_costs": 0,
"transition_duration": 0,
"abnormal_condition_only": false
},
{
"id": "trans1",
"from": "om1",
"to": "om0",
"start_timers": [
"timer1"
],
"blocking_timers": [
"timer0"
],
"transition_costs": 0,
"transition_duration": 0,
"abnormal_condition_only": false
}
],
"timers": [
{
"id": "timer0",
"diagnostic_label": "Minimum run time",
"duration": 7200
},
{
"id": "timer1",
"diagnostic_label": "Minimum off time",
"duration": 3600
}
]
}
And finally, putting everything together in one message:
{
"message_type": "FRBC.SystemDescription",
"message_id": "0f9063c5-ceb9-4ab9-8a4b-96b6d38dff8a",
"valid_from": "2019-08-24T14:15:22Z",
"actuators": [
{
"id": "actuator1",
"diagnostic_label": "heat pump",
"supported_commodities": [
"ELECTRICITY"
],
"operation_modes": [
{
"id": "om0",
"diagnostic_label": "running",
"elements": [
{
"fill_level_range": {
"start_of_range": 45,
"end_of_range": 55
},
"fill_rate": {
"start_of_range": 0.00209,
"end_of_range": 0.00835
},
"power_ranges": [
{
"start_of_range": 500,
"end_of_range": 2000,
"commodity_quantity": "ELECTRIC.POWER.L1"
}
],
"running_costs": {
"start_of_range": 0,
"end_of_range": 0
}
}
],
"abnormal_condition_only": false
},
{
"id": "om1",
"diagnostic_label": "Off",
"elements": [
{
"fill_level_range": {
"start_of_range": 45,
"end_of_range": 55
},
"fill_rate": {
"start_of_range": 0,
"end_of_range": 0
},
"power_ranges": [
{
"start_of_range": 0,
"end_of_range": 0,
"commodity_quantity": "ELECTRIC.POWER.L1"
}
],
"running_costs": {
"start_of_range": 0,
"end_of_range": 0
}
}
],
"abnormal_condition_only": false
}
],
"transitions": [
{
"id": "trans0",
"from": "om0",
"to": "om1",
"start_timers": [
"timer0"
],
"blocking_timers": [
"timer1"
],
"transition_costs": 0,
"transition_duration": 0,
"abnormal_condition_only": false
},
{
"id": "trans1",
"from": "om1",
"to": "om0",
"start_timers": [
"timer1"
],
"blocking_timers": [
"timer0"
],
"transition_costs": 0,
"transition_duration": 0,
"abnormal_condition_only": false
}
],
"timers": [
{
"id": "timer0",
"diagnostic_label": "Minimum run time",
"duration": 7200
},
{
"id": "timer1",
"diagnostic_label": "Minimum off time",
"duration": 3600
}
]
}
],
"storage": {
"diagnostic_label": "DHW Buffer",
"fill_level_label": "temperature",
"provides_leakage_behaviour": true,
"provides_fill_level_target_profile": false,
"provides_usage_forecast": true,
"fill_level_range": {
"start_of_range": 45,
"end_of_range": 55
}
}
}
RM -> CEM: FRBC.LeakageBehaviour
The leakage behavior informs the CEM about the standing losses of the buffer, i.e. all the changes in the fill level that are not associated with the user demand or an actuator. It can be expressed as being dependent on the fill level, such that non-linear leakage can be modelled. A constant leakage rate (in fill_level per second) is defined per fill_level_range. Our buffer has standing losses of 50 W over the range of our fill level.
{
"message_type": "FRBC.LeakageBehaviour",
"message_id": "82861374-7653-4094-9153-8c59b4fffed4",
"valid_from": "2019-08-24T14:15:22Z",
"elements": [
{
"fill_level_range": {
"start_of_range": 45,
"end_of_range": 55
},
"leakage_rate": 0.00005
}
]
}
RM -> CEM: PowerMeasurement
The RM can provide the CEM with real time power values that the appliance consumes. In this case these measurements refer to the electricity consumption of the heat pump.
{
"message_type": "PowerMeasurement",
"message_id": "8db515c2-1ee0-40bb-8820-15c5ddc4bbd3",
"measurement_timestamp": "2019-08-24T14:15:22Z",
"values": [
{
"commodity_quantity": "ELECTRIC.POWER.L1",
"value": 0
}
]
}
RM -> CEM: FRBC.ActuatorStatus
The ActuatorStatus message is meant to communicate the state of the actuator to the CEM. For every actuator, the RM inform the CEM about the operation mode the actuator is in and the factor is uses.
The previous operation mode is also contained in the ActuatorStatus to determine if the actuator is still in the transition phase from the previous operation mode (as specified by the transition_duration in the actuator's transition definition).
{
"message_type": "FRBC.ActuatorStatus",
"message_id": "2d553846-8023-45c4-8e6c-b0e161e60c34",
"actuator_id": "actuator0",
"active_operation_mode_id": "om0",
"operation_mode_factor": 0,
"previous_operation_mode_id": "om1",
"transition_timestamp": "2019-08-24T14:15:22Z"
}
RM -> CEM: FRBC.StorageStatus
With the StorageStatus message the RM updates the CEM about the current fill level.
{
"message_type": "FRBC.StorageStatus",
"message_id": "string",
"present_fill_level": 52
}
RM -> CEM: FRBC.TimerStatus
The moment that a timer elapses after a transition that has been made is communicated via the TimerStatus message. For every timer of all actuators this message is sent from the RM to the CEM.
{
"message_type": "FRBC.TimerStatus",
"message_id": "2ebec2c8-5cd4-46bc-9784-ea125543b544",
"timer_id": "timer0",
"actuator_id": "actuator",
"finished_at": "2019-08-24T14:15:22Z"
}
RM -> CEM: FRBC.UsageForecast
With the UsageForecast, the predicted demand from buffer by the user can be communicated to the CEM. One could think of activities like taking a shower and using hot water for doing the dishes that create the user demand.
The usage forecast is expressed as sequence of expected demand and some statistical values that express the uncertainty of demand on a time slot basis (defined by the duration).
{
"message_type": "FRBC.UsageForecast",
"message_id": "9616e431-5035-404a-bd93-d673a08ebb44",
"start_time": "2019-08-24T14:15:22Z",
"elements": [
{
"duration": 0,
"usage_rate_upper_limit": 0,
"usage_rate_upper_95PPR": 0,
"usage_rate_upper_68PPR": 0,
"usage_rate_expected": 0,
"usage_rate_lower_68PPR": 0,
"usage_rate_lower_95PPR": 0,
"usage_rate_lower_limit": 0
}
]
}
CEM -> RM: FRBC.Instruction
Message that instructs the resource manager to change the actuator state, i.e. change the operation mode and/or operation mode factor. In this example, we change the operation mode of actuator0 (the heat pump) to om0, which is the running operation mode, with factor 1 which means run at maximum power.
{
"message_type": "FRBC.Instruction",
"message_id": "795f10a7-2f5e-4052-90f6-832eecd33dad",
"id": "instr0",
"actuator_id": "actuator0",
"operation_mode": "om0",
"operation_mode_factor": 1,
"execution_time": "2019-08-24T14:15:22Z",
"abnormal_condition": false
}
RM -> CEM: InstructionStatusUpdate
The InstructionStatusUpdate is used by the RM to let the CEM know about the handling of the instruction.
{
"message_type": "InstructionStatusUpdate",
"message_id": "214b4dea-c93c-4567-9b42-6f82ff413ffc",
"instruction_id": "string",
"status_type": "NEW",
"timestamp": "2019-08-24T14:15:22Z"
}
RM -> CEM, CEM -> RM: SessionRequest
Both the RM and the CEM can send a connection life cycle management message, i.e. a SessionRequest message in order to let the other side know to gracefully shut down and if there is a request for a reconnect.
{
"message_type": "SessionRequest",
"message_id": "9b360341-933e-4b83-9128-4ee1c3acfe47",
"request": "TERMINATE",
"diagnostic_label": "string"
}
